If you're interested in more information or purchasing a Layton Bay 22 Center Console,
please fill out the information below and we'll get back to you as soon as we can.

Construction:

  • All fiberglass, hand laid construction using 100% vinyl ester resin and core-cell foam
  • Hull is all fiberglass stringers and composite transom
  • Deck and Liner are fiberglass and core-cell foam core
  • WOOD FREE CONSTRUCTION

Standard Specifications

  • 22'2" Length with Bracket
  • 7'3" Beam at Transom
  • 8'2" Maximum Beam
  • 14" Draft
  • 18" Freeboard
  • 2500 lbs. Dry Weight without Engine
  • 66 Gal Fuel Capacity
  • 12 deg Dead Rise at Transom
  • 200 HP Maximum Power - 46 top speed
  • 36 Cruise speed
  • 4.5 gallon per hour cruise
  • Width is 8'2"
  • Gunnel at rear - 17"
  • Gunnel at console - 21"
  • Gunnel at step-up - 25"

Standard Equipment

  • Standard Color White
  • Hydraulic Steering
  • SS Steering Wheel
  • Space in console for flush mount electronics
  • 12V Blue Sea Switch Panel
  • 12V Blue Sea Fuse Block
  • Blue Sea Battery Switch
  • 1500 GPH Automatic Rule Bilge Pump
  • Compass
  • Horn
  • Interstate Battery
  • LED Running Lights
  • Self Bailing
  • Trim Tab
  • SS Rub Rail
  • 4- SS cleats
  • SS Bow and Stern Eye
  • Raised fwd area w/dry storage
  • Aluminum Leaning Post
  • 224 Qts. Fish Box
  • 2- 75 Qt. Bait/drink boxes
  • Storage under Forward Console Seat
  • Anchor Locker
  • Storage under console w/ side door
  • Stainless steel rod holders
  • Armstrong bracket/platform
Price: $68,900.00
Pricing includes 200HP Suzuki w/ Controls INSTALLED & Armstrong Bracket
**2024 BUYING INCENTIVE** NEXT 3 BUILD SLOTS GET $5,000 ALLOWANCE TOWARDS OPTIONS PACKAGE!
• This package quote is not guaranteed. The price named in the package quote is an approximation. The actual cost may change after all the project elements have been negotiated and finalized. The customer will be informed of any changes in cost in advance. • The market is ever-changing, and these changes have caused price increases in materials, staff, and maintaining the high quality we provide our customers. • So, we can continue to deliver our services at the highest level of quality to you, our prices are subject to change without notice.
